March 24, 2022

Avoiding product loss

Robustness / protection of single use bag

With the RoSS® shell (Robust Storage and Shipping) the single use bag is covered by soft 3D foam, which provides a protective embedding of the single use bag and absorbs the expanding energy of the bag/liquid of about 8% due to the density drop during freezing. The heavy-duty plastic and stainless-steel lids withstand even the lowest temperatures and makes up the robust frame of RoSS®.

The implementation of RoSS® with the effect of a much more robust secondary packaging has diminished the risk of leakages or ruptures towards 0%. The single-use bag and its tubing are perfectly adapted in the RoSS® shell, which in turn maximizes the protective effect. After experiencing the freezing and shipment process with RoSS® for more than 500 times, the product loss has decreased from up to 5% down towards 0%.

product-loss
johannes-kirchmaier

Full immobilization of the frozen single use bag guarantees that the bag, the tubing and all the accessories on the bag do not move at all. So, no breakage happens.

Johannes Kirchmair, CEO

Protein activity / potency

As protein activity should be granted even after scaling up the volumes, the target is to reach the same protein activity for different scales after freezing and/or thawing. A general approach for any protein or when comparing different proteins is not possible due to complex and protein-specific denaturation modes.

Sensitivity to denaturation at the ice liquid interface depends on the protein’s reaction. In collaborations, the DoE (Design of Experiment) regarding the effect of different controlled freezing rates and bag fill volumes was successfully tested on Laccase enzyme activity. Results showed that the controlled freezing in the example of plate freezers has a lower impact on the enzyme activity.

With their slow and not very homogenous freezing processes, traditional static freezers lead to large crystalline structures that are the cause of friction, which in turn leads to the destruction of valuable proteins. Up to 20% of proteins can be destroyed like this. In some circumstances the loss of viral potency can rise to even 56%. Effect: After thawing, the substance has lost a considerable amount of its original concentration, thus dropping in value.1 2 3

Fast controlled freezing with plate-based freezer lead to a more homogeneous freezing with higher protein activity

plate-freezer-fast-freezing-1

Slow uncontrolled freezing (e.g. in static or blast freezer) decreases protein activity by occurring cryoconcentration.

blast-freezer-slow-freezing-1

We have achieved a 0% failure rate out of several batches after implementing RoSS shells

Principal Engineer, Multinational Biotechnology Company

More information

enabling-end-to-end-process-solutions-bottles

Enabling end-to-end process solutions for bottles

The Single Use Support end-to-end process for bottles can be applied independently from bottle manufacturer, it is modular and can be topped off with services such as qualifications, after-sales service and biopharma know-how.

simplyfication-optimizing-performance-efficiency-single-use-technologies

Single-use end-to-end solutions - flexible, scalable and reliable

In an extremely complex, competitive and constantly evolving sector such as the biopharmaceutical industry, flexibility is key, not least since it is an immensely varied and compliance-driven field. Learn more in this article!

optimized-drug-substance-logistics

End-to-end solutions for optimized drug substance logistics

You know about the risk of contamination due to human error with drug substances in the biopharma industry? In this article you will find out why Single Use Support is with its end-to-end solution your partner in the biopharmaceutical market.

efficient-freezing-thawing-vaccines-single-use-technologies

Efficient freezing and thawing of vaccines with single-use technologies

The global distribution of any medical substance requires more than what meets the eye. Before a vaccine can finally be shipped, it needs to be safely processed and contained. Single use technologies offer a number of advantages that cover the entire biopharmaceutical process, including development, manufacturing and logistics.

ebook-advancing-cell-gene-therapies-logistics

eBook: Advancing Cell and Gene Therapies

Putting cell & gene therapies into practice requires complex logistics. Our new eBook will show you solutions to simplify complex process logistics.

  1. TU Wien: Freezing Analyse DoE im LabScale – Final Results, https://, Published 2019
  2. Bezavada A, et al.: Use of Blast Freezers in Vaccine Manufacturing - Bioprocess International, https://bioprocessintl.com/manufacturing/monoclonal-antibodies/use-of-blast-freezers-in-vaccine-manufacture-322317/, Published 2011
  3. Single Use Support: Challenges in Bulk Drug Substance Logistics: eBook, https://www.susupport.com/en/challenges-bulk-drug-substance-logistics/, Published 2020
